Full automatic inner ealoop mask production line
1.Mask finished product size :175*95mm
2.Easy operation
3.Full automatic
4.Stable and fast speed
Left & right earloop rotary welding device
Left&Right earloop conveyor Device
Edge material conveyor Device：
Edge welding device
Mask making machine
Technical Data：
Model | AT-DPJ |
power | 3kw(220V 3 PHASE 50HZ) |
Speed | 180-210 pcs/min |
Machine weight | 850 kg |
Machine size | 2100×600×1200mm（L*W*H） |
Feeding rack size | 1700×600×1400mm（L*W*H） |
Conveyor size | 2800×350×910mm（L*W*H） |
Mask inner earloop welding machine
1. Performance and characteristics:
The machine uses manual rubber band to place in the conveyor belt box. The rubber band at both ends of the mask automatically conveys shearing. The welding is firm. The machine completes the point belt equipment at one time. It has high output, low rejection rate, easy operation, and the appearance adopts the structure of aluminium alloy.
Main Technical Data:
model | AT-NDHJ |
power | 11kw(220V 3 PHASE 50HZ) |
speed | 45~75 pcs/min |
Ultrasonic | 2 set |
Package size | 3000(L)*650(W)*1900(H)mm |
Package weight | 600kg |
pressure | 6kg/c㎡ |
Machine weight | 480kg |
Sample picture:
Detail picture:
FAQ:
♦Payment Methods♦
These payments of T/T, Western Union, CASH are accepted. If you have any problem with the payment, please leave a message to us.
♦Feedback♦
Any comments, suggestions are accepted. We will be very grateful to your positive footprints left in our company. If you have any problem with our products, please leave a message to us.
